Outback Power Systems FLEXMAX 80 User Manual

42
PB
Use the <-DAY> and <+DAY> soft keys to preset the
interval day to initiate an automatic equalization cycle.
The EQ INTERVAL displays the number of days in the
interval between cycles and COUNT displays how many
days of the interval have passed. To view the MAIN EQ
screens, press the <EXIT> soft key.
Press the rst soft key twice to return to the MAIN Menu.
Press the < > soft key until the g is in front of Misc.
Press the <GO> soft key to view the Misc screen.
NOTE:
•
Auto Mode initiates when a preset interval day (1-250 days) is reached.
• The default equalize interval (EQ INTERVAL) setting is 000 day leaving the auto eq disabled.
• EQ-MPPT display indicates the FLEXmax 80 is trying to reach the target equalize set point.
• The equalize time
EQ 0:00 in Hours:Minutes displays after the equalize set point is reached.
• An incomplete equalization cycle continues into the next day unless the FLEXmax 80 is powered o
or manually stopped. The remaining EQ time can be viewed in the Stats Menu.
• The
COUNT value will be cleared to 000 when an EQ is started, manually stopped, or FLEXmax 80 has
been powered o.
• After recharging, an
EQ DONE message displays and a Float cycle begins. EQ DONE is displayed until
(1) any soft key is pressed or (2) a new day occurs for systems using an OutBack MATE.
COUNT EQ INTERVAL
00 000
EXIT -DAY +DAY
BATTERY EQUALIZE
Volts
15.0
EXIT NEXT -EQV +EQV
AUTO MODE
Charger Aux Light
Eq gMisc Advanced
Logging Stats
EXIT f g GO
