Outback Power Systems FLEXMAX 80 User Manual

59
PB
g Charger Aux Light
EQ Misc Advanced
Logging Stats
EXIT f
g GO
Adjusts the Current
Limit, Absorb, and
Float recharging
voltage set points
AUX control includes:
• Vent Fan
• PV Trigger
• Error Output
• Night Light
• Float
• Diversion: Relay
• Diversion: Solid State
• Low Battery Disconnect
• Remote
The Light feature con-
trols the backlighing of
the FLEXmax 80s LCD
screen and soft key
buttons
EQ allows manual or
automatic battery
equalization recharg-
ing
Misc oers additional
settings and service
information
The Advanced menu allows the user to ne-tune
the FLEXmax 80 using the following screens:
• Snooze Mode
• Wakeup Mode
• MPPT Mode
• Park Mpp
• Mpp Range Limit % VOC
• Absorb Time
• Absorb End Amps
• Rebulk Voltage
• Vbatt Calibration
• RTS Compensation
• Auto Restart
• Aux Polarity
• Reset to Defaults?
The Logging screens display
primary and secondary power
production information, including
power peaks
Stats shows time-
based information
regarding the FLEX-
max 80
19. Abbreviated Menu Map
Much of the FLEXmax 80 activity takes place around the MAIN screen. From this screen, the user can
access other screens to both observe system activiy and make adjustments to certain critical functions.
