Outback Comet Kettle K102 - Page 8

8
9
10
Attach the Handle (A3) and Hood Hook (A2) onto the Hood (A1) using M6x12 Bolt
(D1x2pcs), M6 washers (D4X2pcs) and M6 Nuts(D2x2pcs) as shown.
A3
D1
A1
D4
D2
A2
Place the Charcoal Grill (B2) onto the lower brackets in the barbecue body. Ensure the
charcoal grill lies level within the body.
Place the Cooking Grill (B3) onto the upper brackets in the barbecue body. Ensure the
cooking grill lies level within the body.
B2 B3
