11
Attach the Body Heat Shield (B12) to barbecue body using the M5x10 Bolts (D3x2pcs) and
M5 Nuts (D10x2pcs).
14
13
B12
D10
D3
Attach the Flame Tamer Brackets (B5) to barbecue body using the M4x10 Bolts (D4x4pcs)
and M4 Nuts (D9x4pcs).
D9
D4
B5
