6
D12
C8
D11
3
C9
C7
Turn the trolley over so that it stands on its side shelves. Slide the axle (C7) through the corresponding holes
in the short legs (C2). Place a washer (D11) on each end of the axle. Slide the wheels (C8) over each end of
the axle. Secure the wheels into place with the locknuts (D12). Snap the hubcaps (C9) into the wheels.
C2
4
Remove all cast iron cooking components, lava rock baskets,
drip tray, and any internal packaging from the barbecue body.
B1 B2
B4
B3
B9
To Next Page
