Connect the electrode wire to the Ignition Button (B15).
WARNING: BEFORE OPERATION, ENSURE BOTH MAIN BURNER AND
SIDE BURNER WIRES ARE CONNECTED TO PUSH BUTTON IGNITOR.
IF THE CIRCUIT IS NOT COMPLETED, THE IGNITOR WILL NOT SPARK!
Main burner wire
Side burner wire
17
18
B14
Unscrew the pre-assembled nut of the Ignition Button (B15).
Insert the Ignition Button (B15) into the hole at the side burner shelf panel and secure with the
pre-assembled nut.
