Ovation FlashBack-3C User Manual

Issue: 4.7.2134-2 Ovation Systems Ltd Page 8
www.ovation.co.uk
FlashBack-3
Covert Video Recorder
User Guide
Camera DC out
2.1 mm DC Jack Plug
100mm
100mm
Video In
BNC Skt
100mm
100mm
Audio
RCA Phono
Right
Audio Left
RCA Phono
200mm
Audio
Camera
1M
500mm
1M Male to Female
Extension x 2
0.5M Male to Female
Extension x 2
Power + Control
Power
Long Extension
Short Extension
Male
Male
200mm
Audio Right
(Video 2)
Audio Left
(Video 1)
Audio / Video Splitter
Ethernet Socket
RJ45
DC Power IN
2.1 mm Jack Skt
Network
Audio Out Right
Audio Out Left
100mm
Video Out
200mm
Audio/Video Out
Red /(Brown) - DC IN
- Rec Ctl 2
Blue - Rec Ctl 1
Brai
Green
d/(Black) - Ground
Red /(Brown) - Record OK
Green
Blue - Rec Ctl 1
- Rec Ctl 2
Braid /(Black) - Ground
1.5m
Control
1.5 m
Figure 7: FlashBack-3 Dual I-Conex Cable Set
