1. Safe-T-Beam® (STB) Non-Contact Reversing System:
• Places an infrared beam across the door opening.
• Only aects the DOWN travel of the door.
• Stops an open door from closing or reverses a door while in the down travel.
• Reversing system can be overridden with constant pressure on the wired wall console only.
• The door will stop and reverse to the full open position if beam is obstructed.
• Self-diagnostic LEDs on STBs and Powerhead alert to operational issues (See Locating Safe-T-Beam® (for multiple doors) &
Troubleshooting section in this manual for more information).
2. Contact Reversing System:
• Force control automatically reverses a closing door upon contact with an obstruction.
3. Manual Emergency Release pull handle & cord:
• Manually releases door from door opener. Used during a power failure or other emergency to allow manual opening and closing
of the door.
4. Automatic Bluetooth® LED Light Fixture:
• Lighting Fixture turns ON when door is activated and automatically turns OFF 4 minutes later.
• Can be activated/deactivated manually from the wall console.
5. Integrated OHD Anywhere® :
• Available with select models, allows operation of the garage door opener with a secure mobile device application (app) from
OHD Anywhere®.
6. Wireless Wall Console:
• Wireless Wall Console operates door opener from inside garage with an open/close button.
• Manual light control and override.
• OPEN/CLOSE Delay button. Adds an operation delay. Press once for 10 seconds, twice for 20 seconds, three times for 30 seconds.
7. CodeDodger® Encryption, Factory Programmed Remote(s) :
• An encryption system that enhances the security of the door opener by continuously changing the access code each time the
remote is used.
• Factory programmed remote control(s) included with this opener.
Not Shown- Battery Backup (Included on select models) :
• Mounts to bottom of opener and provides power for opener operation during power outages.
1
3
6
7
5
4
2
Vehicle
Compatible
STANDARD AND SAFETY FEATURES
1
1
