OWC Data Doubler Installation

2.2.7 Early / Late 15” MacBook Pro (8,2) and

Mid-2012 15” MacBook Pro (9,1)

IMPORTANT: be sure that your laptop is fully shut down and disconnected

from all cables, including the power cable.

1. Remove the 10 Phillips screws that secure the bottom cover to the chassis.

Note: the three right-most screws along the top edge (shown in yellow) are

longer than the rest; install them in the same screw holes at the end of the

process. The rest can be used interchangeably in the remaining screw holes.

2. Once the screws are removed, place your ngers along the bottom cover

near the black vent, then lift the bottom cover. There are two snap clips

attached to the cover that will release when you do this. Set the cover aside.

Continue to the next page.
