6.To Connect with Computer – Only for OW18B/OW18E
User Interface in MultimeterBLE Software
Move the cursor here to show , click to delete the device
Single device view
Multi-device view
Graph&Table view
Add device
Start offline record
Read offline record
About
Same keys of the multimeter
Scroll to show
other device
Single Device View
Single Device View
Range
AUTO/MANUAL
Function
(Details follow)
Multi-device View
Move the cursor here to show , click to delete the device
Function Description Table
Display
Function
Display
Function
DC
Direct Current
CAP
Measuring Capacitance
AC
Alternating Current
Hz
Measuring Frequency
RES
Measuring Resistance
DUT
Measuring Duty Cycle
DIO
Testing Diodes
TEMP
Measuring Temperature
BEEP
Testing for Continuity
NCV
Non-contact Voltage Detect
