Owon SDS1102 User Manual

2.Safety Terms and Symbols
2
2. Safety Terms and Symbols
Safety Terms
Terms in this manual (The following terms may appear in this manual):
Warning: Warning indicates conditions or practices that could result in injury or
loss of life.
Caution: Caution indicates the conditions or practices that could result in
damage to this product or other property.
Terms on the product. The following terms may appear on this product:
Danger: Indicates an immediate hazard or injury possibility.
Warning: Indicates a possible hazard or injury.
Caution: Indicates potential damage to the instrument or other property.
Safety Symbols
Symbols on the product. The following symbol may appear on the product:
Hazardous Voltage Refer to Manual
Protective Earth Terminal Chassis Ground
Test Ground

Owon SDS1102 Specifications

General

Bandwidth	100 MHz
Sample Rate	1 GS/s
Channels	2
Vertical Sensitivity	2 mV/div to 10 V/div
Connectivity	USB Host, USB Device
Trigger Types	Edge, Pulse, Video, Slope, Alternate
Math Functions	+, -, *, /, FFT
Power Supply	100-240VAC, 50/60Hz
Weight	2.5 kg
Display	7-inch TFT LCD
Vertical Resolution	8 bit
Interface	USB, LAN
Input Impedance	1 MΩ ±2%
