Owon VDS Series User Manual

Performance Characteristics Instruction
Time setting
VDS1022(I)
VDS2052(I)
VDS2062
VDS3102
VDS2064
VDS3104
30ns～10s
Alternate Trigger
Trigger on CH1
Edge, Pulse, *Video, Slope
Trigger on CH2
Edge, Pulse, *Video, Slope
*Video: In alternate trigger, only one channel at most can be set as Video mode.
When VDS1022(I), in alternate trigger, only CH1 can be set as Video mode.
Output of the Probe Compensator
Performance
Characteristics
Instruction
Output Voltage
(Typical )
VDS1022(I)
VDS2052(I)
About 5V, with the Peak-to-Peak
voltage ≥1MΩ.
VDS2062
VDS3102
VDS2064
VDS3104
About 3.3V, with the Peak-to-
Peak
voltage ≥1MΩ.
Frequency (Typical )
Square wave of 1KHz
Power
Mains Voltage
VDS1022(I)
VDS2052(I)
5.0V/500mA
VDS2062(L)
VDS3102(L)
VDS2064
VDS3104
5.0V/1A
Power Consumption
VDS1022(I)
VDS2052(I)
<2.5W
VDS2062(L)
VDS3102(L)
VDS2064
VDS3104
<5W
Environment
Temperature
Working temperature: 0
℃～
40
℃
Storage temperature: -20
℃～
60
℃
Relative Humidity
≤ 90%
Height
Operating: 3,000 m
Non-operating: 15,000 m
Cooling Method
Natural convection
Mechanical Specifications
Dimension
VDS1022(I)
VDS2052(I)
170mm× 120mm×18mm (L*H*W)
VDS2062(L)
VDS3102(L)
VDS2064
VDS3104
190mm× 120mm×18mm (L*W*H)
Weight
About 0.26 kg
Interval Period of Adjustment:
One year is recommended for the calibration interval period.
