Oxford Technical Solutions
77 Heyford Park
Upper Heyford
Oxfordshire
OX25 5HD
www.oxts.com
© Copyright Oxford Technical Solutions, 2019
J1
3
4
Pin Definitions
J1-1 (Brown) Positive 12V Power suppl
y (918V d.c.)
2
1
J1-2 (White) Positive 12V Power/Charge
r supply (1118V d.c.)
J1-3 (Blue) 0V/GND
View from front
J1-4 (Black) 0V/GND
of socket
77C0002B
Parts
Connections
RS291-5881 M12 4w 5m PVC straight
Connector J1-1 (Brown) J2-1
FEC 658-376 Car Cigarette Lighter Plu
g J1-2 (White) J2-1
RS399-524 Yellow Heat Shrink 6.4mm
J1-3 (Blue) J2-2
RS399-934 Clear Heat Shrink 6.4mm
J1-4 (Black) J2-2
(Alternative Part: RS 266-0250
Car Cigarette Lighter Plug - 8A fused)
Fuse
Littelfuse Part Number 0214005 (5A Torpedo
Type Fuse, 25 x 6mm, 36V)
J2
Pin 2
Pin 1
Confidential Information
The information in this document
is confidential and must not be
published or disclosed either wholly
or in part to other parties or used to
build the described components
without the prior written consent of
Oxford Technical Solutions.
0
10
20
30
Print Size: A4
Scale:
1:1
Units:
mm
Tolerances: 1mm
Projection: N/A
Notes:
10/04/02
Alternative Part Number
added
Date: 05/05/11
Part #: 77C0002B
Document:
RT2000 Power Cable
Sheet:
1 of 1
