4 x M1.6x5 Hex Cap Screw
Note: Don't fully tighten yet.
See assembly alignment
Step page 16.
3 x M2x6 Self tapping Screw
Note: Don't use any loctite
6 x M2x6 Hex Cap Screw
Note: Don't fully tighten yet.
Wait future neccessary
assembly step.
Motor Asembly
Boom Clamp Assembly
3 x M2x6 Self
Tapping Screw
Main Frame Assembly Step 2
Main Frame Assembly Step 3
6 x M2x6
Hex Cap Screw
OXY0081-
2.1X5.5X1 Washer
4 x M1.6x5
Hex Cap Screw
page 17
Right Canopy Mount
Assembly.
Chapter 7: Main Frame Assembly
To Next Page
