5
GENERAL INFORMATION
FRONT PANEL FEATURES
PULSE HEAT
3. PULSE HEAT OUTPUTS - Low voltage AC power outputs for Low Voltage, Pulse Heat
handpieces.
4. PULSE HEAT OUTPUT CONTROL - Controls low voltage AC power at PULSE HEAT Outputs.
5. PULSE HEAT LED - Illuminates Green in color when power is applied (by foot pedal through
FOOT PEDAL Selector Switch) to the PULSE HEAT Outputs.
Figure 2. Pulse Heat Section
