34
REPAIR
Figure 13. Removing Front Panel
DISASSEMBLY CONT'D
4. Reposition the unit with the Front Panel of the Power Source facing forward.
5. Remove the 10 Front Panel Mounting Screws.
6. Pull the Front Panel forward 2 inches to expose the interior of the Power Source. DO NOT disconnect
any electrical or air hose connections.
