35
REPAIR
Figure 14. Removing Bolt Assemblies
7. Locate the 4 Bolt Assemblies across the front, inside, bottom edge of the Power Source case.
8. Loosen each of the Hex Nuts on the 4 Bolt Assemblies.
9. Slide each of the Bolt Assemblies forward and remove the assemblies from the Power Source.
