GENERAL INFORMATION
THERMAL MANAGEMENT CENTER
VACUUM AND AIR
Measurements at Front Panel SNAP-VAC and PRESSURE Ports of power source.
Vacuum Rise Time : Evacuates 33 cc (2 cubic inch) volume
to 25 cm Hg. (10 in. Hg.) in 150 ms.
Vacuum: 51 cm Hg. (20 in. Hg.) (nominal)
Pressure: .48 Bar (7 P.S.I.) (nominal, "MAX" setting)
Air Flow: 13 SLPM (0.46 SCFM) maximum
HANDPIECES
Set Temperature Range
of SensaTemp Handpieces: 38°C to 482°C (100°F to 900°F) (see note).
Digital Readout Resolution: ± 1° (°C or °F)
Tip Temperature Stability: ± 1.1°C (± 2°F) at idle from Set Tip Temperature.
NOTE
True minimum and maximum Operating Tip Temperatures may vary
depending on handpiece & tip selection.
EOS/ESD
Tip-To-Ground
Resistance: Less than 5 ohms.
AC Leakage : Less than 2 millivolts RMS from 50Hz to 500Hz.
PIK AND PASTE
Vacuum
(at PIK-VAC Port): 7.6 cm Hg. (3 in. HG.) min.
Pressure
(at PASTE DISP Port): 2.41 Bar (35 P.S.I.) min.
