secured, they will slide out of the extension booms when folding the
crane. This creates a severe risk of fatality for the operator and others.
Before folding the crane push in the mechanical extensions and secure them properly with connection pin and lynch
pin.
Caution! Not maintaining the minimum distances creates an acute
risk of fatality for the operator and others.
Prerequisites for folding the crane
• Extension booms are retracted, pinned and secured.
• No bystanders or obstacles are in the movement range of the crane.
• Ancillary equipment is removed and/or secured, refer to chapter 6.
The operator must have full view of all crane movements.
Operator station:
