Palfinger PC 3800 - Function Labels

Chapter 4 Device and function
Function labels
The function labels are explained below. The order of functions (symbols) may be different on your
operator station from the example shown below. Therefore it is absolutely essential to familiarize
yourself with the symbols and how they are arranged on your device.
Stabilizer cylinder
Retract
Extend
Slewing
Clockwise (right)
Counter-clockwise (left)
Main boom
Lower
Lift (hoist)
Extension boom
Extend
Retract
