Chapter 7 Preparing for crane operation
Vehicle inclination
Only after having supported and levelled the vehicle properly it is allowed to operate the crane.
Declination indicator
5°
When the air bubble is in the middle, the vehicle is levelled.
When the air bubble is between the two circles, the vehicle inclination is
between 0° and 5°.
Work up to 60° boom position
Level the vehicle as horizontal as possible, however within 3° inclination.
Working above 60° boom position
(refer to chapter 8, "Crane working position").
Level the vehicle exactly. The air bubble is in the inner circle.
Danger! Vehicle inclination of more than 1° reduces the guide
function of the extension booms and leads to side loading of the boom
system. There is an acute danger of accident.
Vehicle inclination must not exceed 1° in any direction.
