Panasonic AG-AF100A - Power Sources; Using the Battery and AC Adaptor

25
Preparation
Power sources
Using the battery
Installation
Insert the battery until it clicks into place.
Removal
1
Set the POWER switch to OFF, and check
that the mode lamp is off.
2
Remove the battery while pressing the
battery release button.
Support the battery with your hand to ensure •
that it will not fall.
Mode lamp
Battery
release button
MODE
POWER
CAM
ON
CH2
AUDIO LEVEL
.. OFF
PB
Using the AC adaptor
Installation
1
Connect the DC cord to the AC adaptor.
2
Plug the AC power supply cord into the
power outlet.
3
Insert the DC cord’s battery connector until
it clicks into place.
DC cord’s battery
connector
Removal
1
Set the POWER switch to OFF, and check
that the mode lamp is off.
2
Remove the DC cord’s battery connector
while pressing the battery release button.
3
Disconnect the AC power supply cord from
the power outlet.
Battery cannot be recharged when the DC •
cord is connected to the AC adaptor.
Disconnect the AC power supply cord from the •
power outlet when the unit is not going to be used.
CAUTION:
This apparatus can be operated at a •
voltage in the range of 110 – 240 V AC.
Voltages other than 120 V are not intended
for U.S.A. and Canada.
Operation at a voltage other than 120 V AC
may require the use of a different AC plug.
Please contact either a local or foreign
Panasonic authorized service center for
assistance in selecting an alternate AC plug.
