50
[Audio input]
Built-in microphone
Stereo microphone
XLR input
XLR (3 pin) x 2 (INPUT 1, INPUT 2),
LINE/MIC selectable, high impedance
LINE: 0 dBu
MIC: -50 dBu/-60 dBu (menu selectable)
MIC POWER + 48 V ON/OFF selectable
[AUDIO output]
AUDIO output
 Output:600Ω,316mV
Pin jack × 2 (CH1, CH2)
SDI
2ch (linear PCM)
HDMI
2ch (linear PCM)/5.1ch (Dolby Digital)
Headphone
3.5mm diameter, stereo mini jack × 1
Speaker
Round, 20mm diameter
[Other terminals]
Camera remote terminal
Super mini jack × 1 (2.5 mm diameter) (S/S)
Mini jack × 1 (3.5 mm diameter) (FOCUS, IRIS)
INDEX remote terminal
Super mini jack × 1 (2.5mm diameter)
TC PRESET IN/OUT terminal
VIDEO terminal dual purpose
  IN: 1.0V–4.0V[p-p],10kΩ
OUT: 2.0 V ± 0.5 V [p-p]
Low impedance
USB terminal
Card reader/writer function
(no copyright protection support)
Type mini B connector
(compliant with USB ver. 2.0)
[Monitor]
LCD
3.45 type, wide LCD color monitor
(920,000 dots approx.)
Viewfinder wide
0.45 type LCD color monitor
(1,220,000 dots equivalent approx.)
Specifications (continued)
Weight and dimensions are approximate.
Specifications are subject to change without notice.
[AC adaptor]
Power Source: 110 V - 240 V AC, 50 Hz/60 Hz
22 W
Power Output: 7.3 V DC, 1.75 A
(Camera-recorder)
8.4 V DC, 1.3 A (Charge)
indicates safety information.
Weight
140 g (0.31 lb)
Dimensions (W x H x D)
103 mm × 36 mm × 62 mm
(4-1/16 inches × 1-13/32 inches × 2-7/16 inches)
