Chapter 6 Menu Operations — Menu list
Item Description of settings
[RECORDING CH
SETTING]
[FRONT VR SELECT] Sets the allocation to the <F.AUDIO LEVEL> dial. Enabled when the setting is other than <AUTO>.
[0dB] to [−c] can be adjusted.
[CH1], [CH2], [CH3], [CH4], [CH1/CH2], [CH3/CH4], [ALL], [OFF]
f Factory setting: [OFF]
[AUTO LEVEL CH3] Selects the level setting method for audio channel 3.
[ON]: Sets the mode to adjust automatically. The limiter does not work.
[OFF]: The audio level follows the value for [LEVEL CONTROL CH3].
f Factory setting: [ON]
[AUTO LEVEL CH4] Selects the level setting method for audio channel 4.
[ON]: Sets the mode to adjust automatically. The limiter does not work.
[OFF]: The audio level follows the value for [LEVEL CONTROL CH4].
f Factory setting: [ON]
[LEVEL CONTROL CH3] Can be manually adjusted with this item when automatic level adjustment of audio channel 3 is [OFF].
[0]…[100]
f Factory setting: [70]
[LEVEL CONTROL CH4] Can be manually adjusted with this item when automatic level adjustment of audio channel 4 is [OFF].
[0]…[100]
f Factory setting: [70]
[MIC LOWCUT CH1] Enables/disables the lowcut lter for audio channel 1.
[ON], [OFF]
f Factory setting: [OFF]
[MIC LOWCUT CH2] Enables/disables the lowcut lter for audio channel 2.
[ON], [OFF]
f Factory setting: [OFF]
[MIC LOWCUT CH3] Enables/disables the lowcut lter for audio channel 3.
[ON], [OFF]
f Factory setting: [OFF]
[MIC LOWCUT CH4] Enables/disables the lowcut lter for audio channel 4.
[ON], [OFF]
f Factory setting: [OFF]
[LIMITER CH1] Enables/disables the limiter for audio channel 1.
[ON], [OFF]
f Factory setting: [OFF]
[LIMITER CH2] Enables/disables the limiter for audio channel 2.
[ON], [OFF]
f Factory setting: [OFF]
[LIMITER CH3] Enables/disables the limiter for audio channel 3.
[ON], [OFF]
f Factory setting: [OFF]
[LIMITER CH4] Enables/disables the limiter for audio channel 4.
[ON], [OFF]
f Factory setting: [OFF]
[HEADROOM] Sets the headroom (standard level).
[12dB], [18dB], [20dB]
[OUTPUT SETTING] [AUDIO OUT] Sets the audio signal output from the <AUDIO OUT> terminal, headphone terminal, <HDMI OUT>terminal,
and built-in speaker.
[CH1/2], [CH1], [CH2], [CH3/4], [CH3], [CH4]
f Factory setting: [CH1/2]
[TEST TONE] Outputs rated level 1 kHz tone signal according to the reference level.
The standard level varies depending on the setting of [HEADROOM].
[ON], [OFF]
f Factory setting: [ON]
[OUTPUT SEL]
Congure the settings regarding video output from <SDI OUT>, <HDMI OUT>, <GENLOCK IN/VIDEO OUT>, or <TC IN/OUT> terminal.
Item Description of settings
[SDI OUT] Selects video output from the <SDI OUT> terminal.
[ON]: Outputs video.
[OFF]: Does not output video.
f Factory setting: [OFF]
[SDI&HDMI SELECT] Selects output signals from the <SDI OUT> terminal and <HDMI OUT> terminal.
[SYSTEM MODE]: Follows the setting in [SYSTEM MODE] → [LINE&FREQ].
[1080i]: Converts into interlaced signals and outputs them when [1080-59.94P] or [1080-50P] is selected
in [SYSTEM MODE] → [LINE&FREQ]. This cannot be selected when other settings are made.
[DOWNCON]: Down converts to SD signal and outputs.
f Factory setting: [SYSTEM MODE]
[3G-SDI OUT] Selects 1080P signals of the HD SDI output in 1080P mode.
[LEVEL-A]: Selects the LEVEL-A method.
[LEVEL-B]: Selects the LEVEL-B DL method.
f Factory setting: [LEVEL-B]
