114
Troubleshooting (Advanced)
To save the information as a text file
1 Display the information you want to save.
2 Click [Save].
3 Select the file save range option and click [OK].
4 Select the folder to save the information, input the file name, and click [Save].
z If automatic saving of the management information record has not been disabled, the records already recorded are
also saved.
To save a copy of the screen as an image file
1 Display the screen you want to save.
2 Press
Ctrl
+
Alt
+
Fn
+
K
(F7)
*7
.
*7
For Numeric keyboard model, use a USB keyboard or software keyboard.
3 When the screen copy message appears, click [OK].
The screen image is saved in [Documents] folder.
z Alternatively you can save a copy of the screen in the following procedure.
Click (Start) - [All Programs] - [Panasonic] - [PC Information Viewer] - [Screen Copy].
NOTE
z The image is a bitmap file in 256 colors.
z When using the extended desktop (Î page 76), a copy of the primary device screen is saved.
z The default key combination to copy is
Ctrl
+
Alt
+
Fn
+
K
(F7)
*8
. You can change it in the following procedure.
A Log on to Windows as an administrator.
B Click (Start) - [All Programs] - [Panasonic] - [PC Information Viewer].
C Right-click [Screen Copy] and click [Properties] - [Shortcut].
D Move the cursor to [Shortcut key] and press the key(s) you want to use for the shortcut.
E Click [OK].
*8
For Numeric keyboard model, use a USB keyboard or software keyboard.
