116
REF. NO. PART NAME & DESCRIPTION QTY CU-C24MKF CU-C28MKF REMARK
1 CHASSIS ASS’Y 1 CWD52K1248 CWD50K2100
2 SOUND PROOF MATERIAL 1 CWG302221 CWG302230
3 FAN MOTOR BRACKET 1 CWD541154 CWD541055
4 SCREW - FAN MOTOR BRACKET 4 CWH551217 ←
5 FAN MOTOR 1 CWA951689 ← O
6 SCREW - FAN MOTOR MOUNT 3 CWH55252J ←
7 PROPELLER FAN ASS’Y 1 CWH03K1017 ←
8 NUT - PROPELLER FAN 1 CWH561038J ←
9 COMPRESSOR 1 2JS438D3CB04 2JD514D3AA03 O
10 PACKING 3 CWB81043 ←
11 ANTI - VIBRATION BUSHING 3 CWH50055 ←
12 NUT - COMPRESSOR MOUNT 3 CWH561049 ←
13 CONDENSER 1 CWB32C3094 CWB32C2696
14 CAPILLARY TUBE ASS’Y 1 CWB15K1366 -
15 STRAINER 1 CWB11025 CWB11004
16 HOLDER COUPLING 1 CWH351036 ←
17 2-WAY VALVE (LIQUID) 1 CWB021175 ← O
18 3-WAY VALVE (GAS) 1 CWB011484 ← O
21 TERMINAL COVER 1 CWH171012 ←
22 NUT - TERMINAL COVER 1 CWH7080300J ←
23 SOUND PROOF BOARD 1 CWH151237 CWH151056
24 TERMINAL BOARD ASS’Y 1 CWA28K1064J CWA28K1144
25 TERMINAL BOARD ASS’Y 1 - CWA28C2315
26 CAPACITOR - COM. 1 DS441456CPNC DS441606CPNA O
27 HOLDER CAPACITOR 1 CWH30060 CWH301055
28 CAPACITOR - F.M 1 DS441505NPQB ← O
29 CABINET SIDE PLATE 1 CWE041520A CWE041082A
30 CABINET SIDE PLATE COMPLETE 1 CWE04C1268 CWE04C1126
31 CABINET FRONT PLATE ASS’Y 1 CWE06K1077 CWE06K1045
32 CABINET TOP PLATE 1 CWE031145A CWE03K1011A
33 CONTROL BOARD COVER COMP 1 CWH13C1238 CWH131168
34 HANDLE 1 CWE161010 ←
35 CONTROL BOARD COVER(RIGHT-TOP) 1 CWH131409A CWH131169A
37 THERMOSTAT 1 CWA151061 ←
38 TUBE ASSY(CAP.TUBE,STRAINER) 1 - CWT023253
39 TUBE ASSY(CAPILLARY TUBE) 1 - CWT023148
40 OIL SEPARATER ASS'Y 1 - CWB16K1009
41 ELECTRO MAGNETIC SWITCH 1 - CWA00192
44 WIRE NET 1 CWD041160A CWD041041A
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 00029488).
“O” marked parts are recommended to be kept in stock.
Printed in Malaysia
SY0111-0
