12.2.3 Indoor Unit Installation
12.2.3.1 For the right rear piping
Pull out the Indoor piping
Step-1
Install the Indoor Unit
Step-2
Insert the connecting cable
Step-4
Secure the Indoor Unit
Step-3
12.2.3.2 For the right and right bottom
piping
Pull out the Indoor piping
Step-1
Install the Indoor Unit
Step-2
Insert the connecting cable
Step-4
Secure the Indoor Unit
Step-3
12.2.3.3 For the embedded piping
(This can be used for left rear piping and bottom
piping also.)
To Next Page
