Panasonic CS-C9KKV Service Manual

5
2. Specification
Indoor CS-C9KKV CS-C12KKV
Model
Outdoor CU-C9KKV CU-C12KKV
Performance Test Condition NEW JIS NEW JIS
Phase, Hz Single, 60 Single, 60
Power Supply
V 220 220
kW 2.65 3.56
BTU/h 9040 12140
Capacity
kJ/h 9540 12820
Running Current A 3.9 5.3
Input Power W 830 1.11k
W/W 3.19 3.21
EER
BTU/hW 10.9 10.9
Power Factor % 93 95
dB-A 36 / 26 39 / 29
Indoor Noise (H / L)
Power Level dB 49 / - 52 / -
dB-A 48 / - 48 / -
Cooling
Outdoor Noise (H / L)
Power Level dB 63 63
Max Current (A) / Max Input Power (W) 4.6 / 990 6.5 / 1.35k
Starting Current (A) 23.0 33.0
Type Hermetic Motor Hermetic Motor
Motor Type Induction (2-poles) Induction (2-poles)
Compressor
Output Power W 600 850
Type Cross-Flow Fan Cross-Flow Fan
Material ASG20K1 ASG20K1
Motor Type Induction (4-poles) Induction (4-poles)
Input Power W 51.3 53.2
Output Power W 22 22
QLo rpm 580 680
Lo rpm 650 750
Me rpm 850 930
Hi rpm 1030 1110
Indoor Fan
Speed
SHi rpm 1130 1130
Type Propeller Fan Propeller Fan
Material PP Resin PP Resin
Motor Type Induction (6-poles) Induction (6-poles)
Input Power W 68.2 74.0
Output Power W 30 30
Outdoor Fan
Speed Hi rpm 800 800
Moisture Removal L/h (Pt/h) 1.6 (3.4) 2.1 (4.4)
QLo m
3
/min (ft
3
/min) 5.3 (189) 6.4 (225)
Lo m
3
/min (ft
3
/min) 6.0 (212) 7.0 (248)
Me m
3
/min (ft
3
/min) 7.8 (277) 8.7 (308)
Hi m
3
/min (ft
3
/min) 9.5 (335) 10.4 (367)
Indoor Airflow
SHi m
3
/min (ft
3
/min) 10.4 (368) 10.6 (374)
Outdoor Airflow Hi m
3
/min (ft
3
/min) 29.2 (1030) 32.4 (1140)
Control Device Capillary Tube Capillary Tube
Refrigerant Oil cm
3
ATMOS M60 or SUNISO 4GDID (290) ATMOS M60 or SUNISO 4GDID (350)
Refrigeration
Cycle
Refrigerant Type g (oz) R22, 590 (20.8) R22, 770 (27.2)
Height(I/D / O/D) mm (inch) 290 (11-7/16) 510 (20-3/32) 290 (11-7/16) 540 (21-9/32)
Width (I/D / O/D) mm (inch) 870 (34-9/32) 650 (25-19/32) 870 (34-9/32) 780 (30-23/32)
Dimension
Depth (I/D / O/D) mm (inch) 204 (8-1/16) 230 (9-1/16) 204 (8-1/16) 289 (11-13/32)
Weight Net (I/D / O/D) kg (lb) 9 (20) 23 (51) 9 (20) 29 (64)
