Panasonic CS-C9KKV Service Manual

7
Indoor CS-C18KKV CU-C24KKV
Model
Outdoor CU-C18KKV CU-C24KKV
Performance Test Condition NEW JIS NEW JIS
Phase, Hz Single, 60 Single, 60
Power Supply
V 220 220
kW 5.30 7.03
BTU/h 18100 24000
Capacity
kJ/h 19100 25300
Running Current A 8.0 12.0
Input Power W 1.72k 2.55k
W/W 3.08 2.76
EER
BTU/hW 10.52 9.41
Power Factor % 98 97
dB-A 42 / 37 46 / 40
Indoor Noise (H / L)
Power Level dB - -
dB-A 54 / - 55 / -
Cooling
Outdoor Noise (H / L)
Power Level dB - -
Max Current (A) / Max Input Power (W) 9.06 / 2.07k 14.3 / 2.87k
Starting Current (A) 38.0 63.0
Type Hermetic Motor Hermetic Motor
Motor Type Induction (2-poles) Induction (2-poles)
Compressor
Output Power W 1.2k 1.8k
Type Cross-Flow Fan Cross-Flow Fan
Material ASG30K1 ASG30K1
Motor Type Transistor (8-poles) Transistor (8-poles)
Input Power W 94.8 94.8
Output Power W 40 40
QLo rpm 930 960
Lo rpm 1020 1110
Me rpm 1110 1230
Hi rpm 1200 1350
Indoor Fan
Speed
SHi rpm 1370 1500
Type Propeller Fan Propeller Fan
Material PP Resin PP Resin
Motor Type Induction (6-poles) Induction (6-poles)
Input Power W 151.8 148.4
Output Power W 69 72
Lo rpm - 490
Outdoor Fan
Speed Hi rpm 850 850
Moisture Removal L/h (Pt/h) 2.9 (6.1) 4.0 (8.5)
QLo m
3
/min (ft
3
/min) 12.2 (432) 12.9 (457)
Lo m
3
/min (ft
3
/min) 13.4 (474) 15.0 (528)
Me m
3
/min (ft
3
/min) 14.6 (516) 16.6 (586)
Hi m
3
/min (ft
3
/min) 15.8 (558) 18.2 (642)
Indoor Airflow
SHi m
3
/min (ft
3
/min) 18.0 (637) 20.2 (714)
Outdoor Airflow Hi m
3
/min (ft
3
/min) 51.0 (1800) 51.0 (1800)
Control Device Capillary Tube Capillary Tube
Refrigerant Oil cm
3
ATMOS NM56M or SUNISO 4GDID (650) ATMOS M60 or SUNISO 4GDID (1130)
Refrigeration
Cycle
Refrigerant Type g (oz) R22, 1.33k (46.9) R22, 1.41k (49.8)
Height(I/D / O/D) mm (inch) 290 (11-7/16) 750 (29-17/32) 290 (11-7/16) 750 (29-17/32)
Width (I/D / O/D) mm (inch) 1070 (42-5/32) 875 (34-15/32) 1070 (42-5/32) 875 (34-15/32)
Dimension
Depth (I/D / O/D) mm (inch) 235 (9-9/32) 345 (13-19/32) 235 (9-9/32) 345 (13-19/32)
Weight Net (I/D / O/D) kg (lb) 12 (26) 47 (104) 12 (26) 56 (123)
