Panasonic CS-C9KKV Service Manual

9
Indoor CS-C28KKV
Model
Outdoor CU-C28KKV
Performance Test Condition NEW JIS
Phase, Hz Single, 60
Power Supply
V 220
kW 8.40
BTU/h 28600
Capacity
kJ/h 30240
Running Current A 15.9
Input Power W 3.42k
W/W 2.46
EER
BTU/hW 8.36
Power Factor % 98
dB-A 46 / 44
Indoor Noise (H / L)
Power Level dB -
dB-A 55 / -
Cooling
Outdoor Noise (H / L)
Power Level dB -
Max Current (A) / Max Input Power (W) 19.3 / 4.00k
Starting Current (A) 87.0
Type Hermetic Motor
Motor Type Induction (2-poles)
Compressor
Output Power W 2.4k
Type Cross-Flow Fan
Material ASG30K1
Motor Type Transistor (8-poles)
Input Power W 94.8
Output Power W 40
QLo rpm 1160
Lo rpm 1250
Me rpm 1400
Hi rpm 1490
Indoor Fan
Speed
SHi rpm 1530
Type Propeller Fan
Material PP Resin
Motor Type Induction (6-poles)
Input Power W 160.1
Output Power W 75
Lo rpm 540
Outdoor Fan
Speed
Hi rpm 870
Moisture Removal L/h (Pt/h) 5.0 (10.6)
QLo m
3
/min (ft
3
/min) 15.7 (555)
Lo m
3
/min (ft
3
/min) 16.9 (598)
Me m
3
/min (ft
3
/min) 19.0 (670)
Hi m
3
/min (ft
3
/min) 20.2 (713)
Indoor Airflow
SHi m
3
/min (ft
3
/min) 20.7 (733)
Outdoor Airflow Hi m
3
/min (ft
3
/min) 53.5 (1890)
Control Device Capillary Tube
Refrigerant Oil cm
3
ATMOS NM56M or SUNISO 4GDID (900)
Refrigeration
Cycle
Refrigerant Type g (oz) R22, 1.96k (69.2)
Height(I/D / O/D) mm (inch) 290 (11-7/16) 750 (29-17/32)
Width (I/D / O/D) mm (inch) 1070 (42-5/32) 875 (34-15/32)
Dimension
Depth (I/D / O/D) mm (inch) 235 (9-9/32) 345 (13-19/32)
Weight Net (I/D / O/D) kg (lb) 12 (26) 63 (139)
