<Model: CS-E10HB4EA CS-E15HB4EA CS-E18HB4EA CS-E21HB4EAS>
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
REF.
NO.
PARTS NAME & DESCRIPTION QTY CS-E10HB4EA CS-E15HB4EA CS-E18HB4EA CS-E21HB4EAS REMARKS
1 BASE PAN ASS’Y 1 CWD52K1100 ←←←
2 INNER POLYSTYRENE COMPLETE 1 CWG07C1047 ←←←
3 CABINET SIDE PLATE ASS’Y 1 CWE041121 ←←←
4 CABINET SIDE PLATE ASS’Y 1 CWE041122 ←←←
5 LEAD WIRE - FAN MOTOR 1 CWA67C5136 ←←←
6 FAN MOTOR 1 EHDS50A40AC ←←←O
7 ANTI - VIBRATION BUSHING 3 CWH501065 ←←←
8 CORD HOLDER 1 CWD741024 ←←←
9 SCREW - FAN MOTOR 3 CWH561058 ←←←
11 TURBO FAN 1 CWH03K1022 ←←←
12 NUT for TURBO FAN 1 CWH561042 ←←←
13 SPRING WASHER 1 XWA8BFJ ←←←
14 PLAIN WASHER 1 XWG8H22FJ ←←←
15 EVAPORATOR COMPLETE 1 CWB30C2522 CWB30C2521 ←←
16 FLARE NUT (3/8”) or (1/2”) 1 CWT251031 CWT251032 ←←
17 HEATPROOF TUBE 1 CWG021024 ←←←
18 HEATPROOF TUBE 1 CWG021064 ←←←
19 FLARE NUT (1/4”) 1 CWT251030 ←←←
21 PIPE COVER 1 CWD93C1050 ←←←
22 SENSOR - EVAPORATOR 1 CWA50C2549 ←←←
23 SENSOR HOLDER 2 CWH32143 ←←←
24 EVAPORATOR SUPPORTER 3 CWD911529A ←←←
25 TUBE ASS’Y (CAP. TUBE - EVA) 1 CWT07K1188 ←←←
26 DRAIN PUMP COMPLETE 1 CWB53C1015 ←←←
27 PANEL DRAIN PUMP ASS’Y 1 CWD93K1021 ←←←
28 DRAIN PUMP 1 CWB532043J ←←←
29 ANTI - VIBRATION BUSHING 3 CWH501080 ←←←
30 FLOAT SWITCH - DRAIN PUMP 1 CWA121233 ←←←
31 FLEXIBLE PIPE 1 CWH85C1033 ←←←
32 DRAIN NOZZLE 1 CWH411011 ←←←
33 DRAIN HOSE HEAT INSULATION 1 CWG321050 ←←←
35 DRAIN PAN - COMPLETE 1 CWH40C1034 ←←←
36 DRAIN PLUG 1 CWB821008 ←←←
37 AIR GUIDER BLOWER WHEEL 1 CWD321058 ←←←
38 CONTROL BOARD CASING 1 CWH10K1102 ←←←
39 ELECTRONIC CONTROLLER (MAIN) 1 CWA73C3335 CWA73C3336 CWA73C3337 CWA73C3338 O
40 LOCKING GUARD SPACER 6 CWH541026 ←←←
41 TRANSFORMER 1 CWA40C1030 ←←←
43 TERMINAL BOARD ASS’Y 1 CWA28K1192 ←←←O
44 LEADWIRE-AIR TEMP. SENSOR 1 CWA67C5751 ←←←O
47 CONTROL BOARD COVER 1 CWH13C1182 ←←←
48 ACCESSORY COMPLETE 1 CWH82C1270 ←←←
48A HEATPROOF TUBE 1 CWG021025 ←←←
51 REMOTE CONTROL COMPLETE 1 CWA75C3208 ←←←O
52 OPERATING INSTRUCTION 1 CWF566070 ←←←
53 OPERATING INSTRUCTION 1 CWF566071 ←←←
54 INSTALLATION INSTRUCTION 1 CWF613465 ←←←
