Indoor CS-E12PKEW, CS-XE12PKEW CS-E15PKEW, CS-XE15PKEW
Model
Outdoor CU-E12PKE CU-E15PKE
Type Hermetic Motor (Rotary) Hermetic Motor (Rotary)
Motor Type Brushless (6 poles) Brushless (6 poles)
Compressor
Output Power W 700 700
Type Cross-Flow Fan Cross-Flow Fan
Material ASG33 ASG33
Motor Type DC / Transistor (8-poles) DC / Transistor (8-poles)
Input Power W 44.9 44.9
Output Power W 40 40
Cool rpm 570 660
QLo
Heat rpm 630 800
Cool rpm 710 760
Lo
Heat rpm 940 980
Cool rpm 910 960
Me
Heat rpm 1070 1110
Cool rpm 1110 1150
Hi
Heat rpm 1190 1230
Cool rpm 1170 1190
Indoor Fan
Speed
SHi
Heat rpm 1220 1270
Type Propeller Fan Propeller Fan
Material PP PP
Motor Type DC (8-poles) DC (8-poles)
Input Power W – –
Output Power W 40 40
Cool rpm 900 900
Outdoor Fan
Speed Hi
Heat rpm 910 910
Moisture Removal L/h (Pt/h) 2.0 (4.2) 2.4 (5.1)
Cool m
3
/min (ft
3
/min) 6.71 (237) 850 (300)
QLo
Heat m
3
/min (ft
3
/min) 7.54 (266) 9.87 (348)
Cool m
3
/min (ft
3
/min) 8.63 (305) 9.59 (339)
Lo
Heat m
3
/min (ft
3
/min) 11.79 (416) 12.34 (436)
Cool m
3
/min (ft
3
/min) 11.38 (402) 12.06 (426)
Me
Heat m
3
/min (ft
3
/min) 13.44 (475) 13.98 (494)
Cool m
3
/min (ft
3
/min) 13.9 (490) 14.1 (500)
Hi
Heat m
3
/min (ft
3
/min) 14.3 (505) 15.0 (530)
Cool m
3
/min (ft
3
/min) 14.95 (528) 15.22 (537)
Indoor
Airflow
SHi
Heat m
3
/min (ft
3
/min) 15.63 (552) 16.32 (576)
Cool m
3
/min (ft
3
/min) 33.3 (1175) 33.3 (1175)
Outdoor
Airflow
Hi
Heat m
3
/min (ft
3
/min) 33.3 (1175) 33.3 (1175)
Control Device Check Valve & Capillary Tube Check Valve & Capillary Tube
Refrigerant Oil cm
3
FV50S (320) FV50S (320)
Refrigeration
Cycle
Refrigerant Type g (oz) R410A, 1.05k (37.1) R410A, 1.02k (36.0)
Height (I/D / O/D) mm (inch) 295 (11-5/8) / 619 (24-3/8) 295 (11-5/8) / 619 (24-3/8)
Width (I/D / O/D) mm (inch) 870 (34-9/32) / 824 (32-15/32) 870 (34-9/32) / 824 (32-15/32)
Dimension
Depth (I/D / O/D) mm (inch) 255 (10-1/16) / 299 (11-25/32) 255 (10-1/16) / 299 (11-25/32)
Weight Net (I/D / O/D) kg (lb) 10 (22) / 34 (75) 10 (22) / 33 (73)

Panasonic CS-E7PKEW Specifications

General

Indoor unit type	Wall-mountable
Indoor unit weight	10000 g
Indoor units quantity	1
Cooling airflow (indoor unit)	732 m³/h
Heating airflow (indoor unit)	768 m³/h
Indoor unit dimensions (WxDxH)	870 x 255 x 295 mm
Indoor unit noise level (high speed)	38 dB
Type	Air conditioner indoor unit
Ionizer	-
Remotely operated	Yes
Cooling capacity (max)	7000 BTU/h
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (max)	2400 W
Cooling capacity in watts (min)	750 W
Heating capacity in watts (max)	2800 W
Cooling energy efficiency (EER, W/W)	4.41
Heating energy efficiency (COP, W/W)	4.44
Seasonal efficiency rating (cooling) (SEER)	6.7
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4.3
Noise level (low speed)	20 dB
Noise level (medium speed)	25 dB
Power requirements	230V, 10A
Power consumption (cooling) (max)	- W
Power consumption (heating) (max)	1010 W
Power consumption (heating) (min)	230 W
Annual energy consumption (cooling)	110 kWh
Annual energy consumption (heating) (Average heating season)	684 kWh
