Panasonic CS-E7PKEW User Manual

11
Indoor CS-E12PKEW, CS-XE12PKEW CS-E15PKEW, CS-XE15PKEW
Model
Outdoor CU-E12PKE CU-E15PKE
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 9.52 (3/8) 6.35 (1/4) / 12.70 (1/2)
Standard length m (ft) 5.0 (16.4) 5.0 (16.4)
Length range (min – max) m (ft) 3 (9.8) ~ 15 (49.2) 3 (9.8) ~ 15 (49.2)
I/D & O/D Height different m (ft) 15.0 (49.2) 15.0 (49.2)
Additional Gas Amount g/m (oz/ft) 20 (0.2) 20 (0.2)
Piping
Length for Additional Gas m (ft) 7.5 (24.6) 7.5 (24.6)
Inner Diameter mm 16.7 16.7
Drain Hose
Length mm 650 650
Fin Material Aluminium (Pre Coat) Aluminium (Pre Coat)
Fin Type Slit Fin Slit Fin
Row × Stage × FPI 2 × 17 × 17 2 × 17 × 17
Indoor Heat
Exchanger
Size (W × H × L) mm 636.5 × 357 × 25.4 636.5 × 357 × 25.4
Fin Material Aluminium Aluminium
Fin Type Corrugated Fin Corrugated Fin
Row × Stage × FPI 2 × 28 × 17 2 × 24 × 17
Outdoor
Heat
Exchanger
Size (W × H × L) mm 36.4 × 588 × 606.6 36.4 × 588 × 606.6
Material Polypropelene Polypropelene
Air Filter
Type One-touch One-touch
Power Supply Indoor Indoor
Power Supply Cord A Nil Nil
Thermostat Electronic Contol Electronic Contol
Protection Device Electronic Contol Electronic Contol
Dry Bulb Wet Bu b Dry Bulb Wet Bu b
Maximum °C 32 23 32 23
Cooling
Minimum °C 16 11 16 11
Maximum °C 30 – 30 –
Indoor
Operation
Range
Heating
Minimum °C 16 – 16 –
Maximum °C 43 26 43 26
Cooling
Minimum °C -10 – -10 –
Maximum °C 24 18 24 18
Outdoor
Operation
Range
Heating
Minimum °C -15 -16 -15 -16
1. Cooling capacities are based on indoor temperature of 27°C Dry Bulb (80.6°F Dry Bulb), 19.0°C Wet Bulb (66.2°F Wet Bulb) and outdoor air
temperature of 35°C DRY BULB (95°F Dry Bulb), 24°C Wet Bu b (75.2°F Wet Bulb)
2. Heating capacities are based on indoor temperature of 20°C Dry Bulb (68°F Dry Bu b) and outdoor air temperature of 7°C Dry Bulb (44.6°F
Dry Bu b), 6°C Wet Bulb (42.8°F Wet Bulb)
3. Heating low temperature capacity, Input Power and COP measured at 230 V, indoor temperature 20°C, outdoor 2/1°C
4. Heating extreme low temperature capacity, Input Power and COP measured at 230 V, indoor temperature 20°C, outdoor -7/-8°C
5. Standby power consumption ≤0.7w (when switched OFF by remote control, except under self protection control).
6. Specifications are subjected to change without prior notice for further improvement.

Panasonic CS-E7PKEW Specifications

General

Indoor unit type	Wall-mountable
Indoor unit weight	10000 g
Indoor units quantity	1
Cooling airflow (indoor unit)	732 m³/h
Heating airflow (indoor unit)	768 m³/h
Indoor unit dimensions (WxDxH)	870 x 255 x 295 mm
Indoor unit noise level (high speed)	38 dB
Type	Air conditioner indoor unit
Ionizer	-
Remotely operated	Yes
Cooling capacity (max)	7000 BTU/h
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (max)	2400 W
Cooling capacity in watts (min)	750 W
Heating capacity in watts (max)	2800 W
Cooling energy efficiency (EER, W/W)	4.41
Heating energy efficiency (COP, W/W)	4.44
Seasonal efficiency rating (cooling) (SEER)	6.7
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4.3
Noise level (low speed)	20 dB
Noise level (medium speed)	25 dB
Power requirements	230V, 10A
Power consumption (cooling) (max)	- W
Power consumption (heating) (max)	1010 W
Power consumption (heating) (min)	230 W
Annual energy consumption (cooling)	110 kWh
Annual energy consumption (heating) (Average heating season)	684 kWh
