Panasonic CS-RE9NKR - Heating Operation; Automatic Operation

26
12.1.4 Heating operation
12.1.4.1 Thermostat control
• Compressor is OFF when Intake Air Temperature - Internal Setting Temperature > +2.0℃
• Compressor is ON after waiting for 3 minutes, if the Intake Air Temperature - Internal Setting Temperature<
Compressor OFF point -0.5K.
12.1.5 Automatic Operation
• Once AUTO mode is selected, operation mode is determined by set temperature of remote control and indoor
intake temperature.
1st judgment
JUDGE CONDITION REFERANCE MODE
If indoor intake temp – Remote control
temp setting ≥ +2
Cool mode
If -2 ≤ indoor intake temp. – Remote
control Temp. setting ≤ +2
Dry mode
If indoor intake temp. – Remote control
temp. setting < -2
Heat mode
2nd & following judgment (every 10 minutes after 1st judgment)
Intake temp.- setting temp.
DRY
COOL
HEAT
-
6
-
5
-
4
-
3
-
2
-
1 0 1 2 3
4 5 6
