Panasonic CS-RE9NKR Service Manual

5
2. Specification
Model Indoor CS-RE9NKR CS-RE12NKR
Outdoor CU-RE9NKR CU-RE12NKR
Power Supply Phase, Hz Single, 50 Single, 50
V 230-240 230-240
Min Rate Max Min Rate Max
kW 0.90 2.50 3.00 0.90 3.50 3.90
BTU/h 3070 8530 10230 3070 11940 13300
Capacity
kcal/h 770 2150 2580 770 3010 3350
Running Current A - 3.10-3.05
- - 4.20-4.10
-
Input Power W 190 650 1000 170 940 1200
W/W 4.74 3.84 3.00 5.29 3.72 3.25
EER
BTU/hW 16.16 13.12 10.23 18.06 12.70 11.08
Power Factor % 91-89 97-95
dB-A(H / L / QLo)
Hi: 42 Lo: 27 QLo: 22 Hi: 42 Lo: 30 QLo: 22
Indoor Noise
Power Level 58 58
dB-A (H / L ) Hi: 47 Lo: - Hi: 48 Lo: -
COOLING
Outdoor Noise
Power Level 63 64
kW 0.90 3.30 4.10 0.90 4.25 5.10
BTU/h 3070 11250 13980 3070 14490 17390
Capacity
kcal/h 770 2840 3530 770 3660 4390
Running Current A - 3.80-3.75
- - 5.00-4.90
-
Input Power W 170 810 1150 150 1100 1460
W/W 5.29 4.07 3.57 6.00 3.86 3.49
COP
BTU/hW 18.06 13.88 12.16 20.47 13.17 11.91
Power Factor % 92-90 95-93
dB-A(H / L / QLo)
Hi: 42 Lo: 27 QLo: 25 Hi: 42 Lo: 33 QLo: 25
Indoor Noise
Power Level 58 58
dB-A (H / L ) Hi: 48 Lo: - Hi: 50 Lo: -
HEATING
Outdoor Noise
Power Level 64 66
Max Current (A) / Max Input Power (W) 6.00 / 1.420k 8.10 / 1.920k
Starting Current (A) 4.20 6.40
Type Hermetic Motor compressor
Hermetic Motor compressor
Motor Type BRUSHLESS (6 poles) BRUSHLESS (6 poles)
Compressor
Output Power W 750 1100
Type Cross-flow fan Cross-flow fan
Material AS(GF30%) AS(GF30%)
Motor Type DC (8 poles) DC (8 poles)
Input Power W 35.20 35.20
Output Power W 30 30
Q-Lo rpm 600 620
Lo rpm 700 790
Me rpm 920 970
Speed
(COOLING)
Hi rpm 1170 1170
Q-Lo rpm 650 680
Lo rpm 710 830
Me rpm 830 950
Indoor Fan
Speed
(HEATING)
Hi rpm 1120 1150
Type Propeller Propeller
Material PP(GF+PD)30% PP(GF+PD)30%
Motor Type AC (6 poles) DC (8 poles)
Input Power W 67.1 97.46
Output Power W 25 40
Hi(C) rpm 680 720
Outdoor Fan
Speed
Hi(H) rpm 660 880
Moisture Removal L/h (Pt/h) 1.4 (2.4) 2.0 (3.5)
Q-Lo m
3
/min (ft
3
/m) 6.36(224) 6.73 (237)
Lo m
3
/min (ft
3
/m) 7.42(261) 8.58 (302)
Me m
3
/min (ft
3
/m) 9.75(344) 10.53 (371)
Indoor Airflow
(COOLING)
Hi m
3
/min (ft
3
/m) 12.4 (437) 12.7 (448)
