52
No.
Parts Name Q'ty
CS-RE9NKR CS-RE12NKR REMARK
1 CHASSIS COMPLETE 1 CWD50C1745 CWD50C1745
2 FAN MOTOR(DC,280-340V,30W) 1 ARW7648AC ARW7648AC
3 CROSS FLOW FAN COMPLETE 1 CWH02C1095 CWH02C1095
4 EVAPORATOR 1 CWB30C4138 CWB30C3977
5 AUXILIARY TUBE ASS'Y 1 CWT01C5455 CWT01C5455
6 DRAIN PLUG 1 CWH521096 CWH521096
7 DISCHARGE GRILLE COMPLETE 1 CWE20C3276 CWE20C3276
8 AIR SWING MOTOR(DC,12V,200Ω) 1 CWA981292 CWA981292
9 HORIZONTAL AIR FLOW VANE (L) 1 CWE24C1291 CWE24C1291
10
HORIZONTAL AIR FLOW VANE (R) 1 CWE24C1292 CWE24C1292
11
VERTICAL AIR FLOW VANE 1 CWE24C1413 CWE24C1413
12
C-BOX 1 CWH14C9439 CWH14C9440
13
CONTROL BOARD CASING 1 CWH102487 CWH102487
14
PARTICULAR PIECE 1 CWD933089 CWD933089
15
TERMINAL BOARD COMPLETE 1 CWA28C2547 CWA28C2547
16
POWER SUPPLY CORD COMPLETE 1 CWA20C3067 CWA20C3067
17
MAIN PCB 1 CWA73C6074 CWA73C6075
18
SENSOR 1 CWA50C2883 CWA50C2883
19
INDICATOR HOLDER-FRONT 1 CWD933546 CWD933546
20
INDICATOR PCB 1 CWA746860 CWA746860
21
CONTROL BOARD TOP COVER 1 CWH131523 CWH131523
22
CONTROL BOARD BACK COVER 1 CWH131526 CWH131526
23
REMOTE CONTROL 1 CWA75C3755 CWA75C3755
24
FRONT GRILLE COMPLETE 1 CWE11C5307 CWE11C5307
25
INTAKE GRILLE 1 CWE22K1594 CWE22K1594
26
GRILLE DOOR 1 CWE14C1092 CWE14C1092
27
AIR FILTER 2 CWD001339 CWD001339
28
ANTI-BACTERIAL FILTER 1 CWD001280 CWD001280
29
SCREW-FRONT GRILLE 2 CWXTT4+16CFJ
CWXTT4+16CFJ
30
CAP-FRONT GRILLE 2 CWH521236A CWH521236A
31
DRAIN HOSE 1 CWH851136 CWH851136
32
OPERATING INSTRUTIONS 1 CWF568478 CWF568478
33
INSTALLATION INSTRUCTION 1 CWF615267 CWF615267
34
INSTALLATION PLATE 1 CWH361133 CWH361133
(Note)
• All parts are supplied from PHAAG, China
