Panasonic CS-RE9NKR Service Manual

54
No.
Parts Name Q'ty
CU-RE9NKR CU-RE12NKR REMARK
1 CHASSIS ASS'Y 1 CWD52K1262A CWD52K1303A
2 FAN MOTOR BRACKET 1 CWD541182 CWD541182
3 SCREW-FAN MOTOR BRACKET 2 CWH551148A CWH551148A
4 FAN MOTOR(AC,220-240V,25W) 1 CWA951814 ARS8405AC
5 SCREW-FAN MOTOR MOUNT 4 CWH551148A CWH551148A
6 PROPELLER FAN ASS'Y 1 CWH03K1059 CWH03K1078
7 NUT-PROPELLER FAN 1 CWH561098 CWH561034J
8 COMPRESSOR 1 CWB092635 CWB092574
9 ANTI-VIBRATION BUSHING 3 CWH501038 CWH501022
10
NUT-COMPRESSOR MOUNT 3 CWH561096 CWH561096
11
CONDENSER 1 CWB32C3573PA CWB32C3579PA
12
HOLDER COUPLING ASS'Y 1 CWH351191A CWH351191A
13
4-WAY VALVE 1 CWB001063 CWB001063
14
2-WAY VALVE 1 CWB021531 CWB021531
15
3-WAY VALVE 1 CWB011645 CWB011645
16
TERMINAL COVER 1 CWH171041 CWH171048
17
NUT FOR TERMINALA COVER 1 - CW7080300J
18
PLATE SPRING 1 CWH71044 -
19
SOUND PROOF BOARD 1 CWH15K1034 CWH15K1060
20
SOUND PROOF MATERIAL 1 CWG302412 CWG302609
21
SOUND PROOF MATERIAL 1 CWG302471 CWG302682
22
STRAITER 1 CWB141023 CWB141023
23
REACTOR 1 G0C193J00011 G0C193J00014
24
CONTROL BOX COMPLETE 1 CWH14C9415 CWH14C9417
25
ELECTRONIC CONTROLLER(DRED) 1 CWA746902 CWA746902
26
TERMINAL BOARD ASS'Y 1 CWA28K1248 CWA28K1248
27
TERMINAL BOARD ASS'Y(DRED) 1 CWA28K1270 CWA28K1270
28
SENSOR COMPLETE(COMP.) 1 CWA50C2834 CWA50C2209J
29
SENSOR COMPLETE(PIPING) 1 CWA50C2882 CWA50C2766
30
CAPILLARY COMPLETE 1 CWT01C6211 CWT01C6013
31
V-COIL COMPLETE FOR 4-WAY VALVE 1 CWA43C2472 CWA43C2472
32
TOP PLATE 1 CWE03K1061A CWE03K1061A
33
CABINET FRONT PLATE 1 CWE06C1337 CWE06C1337
34
DISCHARGE GRILLE 1 CWE201195 CWE201195
35
CABINET SIDE PLATE 1 CWE04C1385 CWE04K1154A
36
CONTROL BOARD COVER 1 CWH131402A CWH131402A
37
HANDLE 1 CWE16037C CWE16037C
38
DRAIN ELBOW 1 CWT201212 CWT201212
(Note)
• All parts are supplied from PHAAG, China.
Printed in China
