Panasonic CS-TZ25TKEW Service Manual

13
Model
Indoor CS-TZ35TKEW CS-TZ42TKEW
Outdoor CU-TZ35TKE CU-TZ42TKE
Compressor
Type Hermetic Motor (Rotary) Hermetic Motor (Rotary)
Motor Type Brushless (6 poles) Brushless (6 poles)
Output Power W 700 700
Indoor Fan
Type Cross-Flow Fan Cross-Flow Fan
Material ASG20K1 ASG20K1
Motor Type DC / Transistor (8-poles) DC / Transistor (8-poles)
Input Power W 47.3 47.3
Output Power W 30 30
Speed
QLo
Cool rpm 630 870
Heat rpm 730 920
Lo
Cool rpm 900 930
Heat rpm 1020 1100
Me
Cool rpm 1100 1170
Heat rpm 1200 1280
Hi
Cool rpm 1310 1410
Heat rpm 1380 1470
SHi
Cool rpm 1360 1460
Heat rpm 1430 1500
Outdoor Fan
Type Propeller Fan Propeller Fan
Material PP PP
Motor Type DC (8-poles) DC (8-poles)
Input Power W – –
Output Power W 40 40
Speed Hi
Cool rpm 830 900
Heat rpm 880 910
Moisture Removal L/h (Pt/h) 2.0 (4.2) 2.4 (5.1)
Indoor
Airflow
QLo
Cool m
3
/min (ft
3
/min) 5.27 (186) 7.21 (255)
Heat m
3
/min (ft
3
/min) 6.23 (220) 7.69 (272)
Lo
Cool m
3
/min (ft
3
/min) 7.86 (278) 7.78 (275)
Heat m
3
/min (ft
3
/min) 9.02 (319) 9.40 (332)
Me
Cool m
3
/min (ft
3
/min) 9.78 (345) 10.06 (355)
Heat m
3
/min (ft
3
/min) 10.74 (379) 12.11 (428)
Hi
Cool m
3
/min (ft
3
/min) 11.80 (415) 12.30 (435)
Heat m
3
/min (ft
3
/min) 12.50 (440) 12.90 (455)
SHi
Cool m
3
/min (ft
3
/min) 12.28 (434) 12.82 (453)
Heat m
3
/min (ft
3
/min) 12.35 (436) 13.20 (466)
Outdoor
Airflow
Hi
Cool m
3
/min (ft
3
/min) 28.70 (1015) 33.60 (1185)
Heat m
3
/min (ft
3
/min) 30.40 (1075) 34.00 (1200)
Refrigeration
Cycle
Control Device Expansion Valve Expansion Valve
Refrigerant Oil cm
3
FW50S (320) FW50S (320)
Refrigerant Type g (oz) R32, 770 (27.2) R32, 860 (30.4)
F-Gas
GWP 675 675
CO2eq (ton)
(Precharged Amount /
Maximum Charged Amount)
0.520 / 0.570 0.581 / 0.631
Dimension
Height (I/D / O/D) mm (inch) 290 (11-7/16) / 542 (21-11/32) 290 (11-7/16) / 619 (24-3/8)
Width (I/D / O/D) mm (inch) 799 (31-15/32) / 780 (30-23/32) 799 (31-15/32) / 824 (32-15/32)
Depth (I/D / O/D) mm (inch) 197 (7-25/32) / 289 (11-13/32) 197 (7-25/32) / 299 (11-25/32)
Weight Net (I/D / O/D) kg (lb) 8 (18) / 32 (71) 8 (18) / 32 (71)
