14 Replacement Parts List
<Model: CS-A12CTP / CS-A18CTP / CS-A24CTP>
REF NO. DESCRIPTION & NAME QTY. CS-A12CTP CS-A18CTP CS-A24CTP REMARKS
1 CHASSY COMPLETE 1 CWD50C1258
← ←
2 FAN MOTOR 1 CWA921172
←
CWA921158 O
3 SUPPORTER FAN MOTOR 2 CWD932270
← ←
4 BLOWER WHEEL ASSY 2 CWH01K1014
← ←
5 AIR GUIDER B.W. 2 CWD321046
← ←
6 CONTROL BOARD ASSY 1 CWH10K1030
← ←
7 CAPACITOR 1 DS441155BLSA
(1.5 µF/440V)
←
DS441305SLTA
(3.0 µF/440V)
O
8 TERMINAL BOARD ASSY 1 CWA28K1063
← ←
O
9 TRANSFORMER 1 CWA401030
← ←
O
10 ELECTRONIC CONTROLLER 1 CWA742919 CWA742921 CWA743059 O
11 SENSOR ASSY COMP 1 CWA50C2157
← ←
O
12 LEAD WIRE FAN MOTOR 1 CWA67C4431
← ←
13 LEAD WIRE FAN MOTOR 1 CWA67C4474
← ←
14 EVAPORATOR 1 CWB30C1280 CWB30C1314 CWB30C1313
15 SUPPORTER TUBE ASSY 1 CWD932259
← ←
16 FLARE NUT 1 CWT25007
←
CWT25004
17 DRAIN PAN COMPLETE 1 CWH40C1023
← ←
18 TAP DRAIN TRAY 1 CWH401031
← ←
19 DISCHARGE GRILLE COMPLETE 1 CWE20C2223
←
CWE20C2189
20 DISCHARGE GRILLE 1 CWE201046
← ←
21 VANE-AIR SWING 1 CWE241124
← ←
22 CONNECTING BAR 2 CWE261052
← ←
23 CONNECTING BAR 2 CWE261053
← ←
24 VANE 14 CWE241126
← ←
O
25 AIR SWING MOTOR 1 CWA981085
← ←
O
26 INDICATOR COMP. 1 CWE39C1069
← ←
27 LEAD WIRE INDICATOR 1 CWA67C4433
← ←
28 CONTORL BOARD CASING ASSY 1 CWH13K1009
← ←
31 INTAKE GRILLE 1 CWE221084
← ←
32 AIR FILTER 2 CWD001088
← ←
33 REMOTE CONTROL COMPLETE 1 CWA75C2318
← ←
O
34 REMOTE CONTROL HOLDER 1 CWH361022
← ←
35 POWER SUPPLY CORD 1 CWA20C2286 CWA20C2285 CWA20C2284
36 DRAIN HOSE 1 CWH85284
← ←
37 INSTALLATION HOLDER 1 CWH361018
← ←
38 ACCESSORY COMPLETE 1 CWH82C1166
←
CWH82C1156
39 FULCRUM 3 CWH621030
← ←
40 FRONT GRILLE 1 CWE11C2767
← ←
41 STRING COMPLETE 1 CWH84C1006
← ←
(Note)
•
All parts are supplied from MAICO, Malaysia (Vendor Code: 061).
•
“O” marked parts are recommended to be kept in stock.
56
CS-A12CTP CU-A12CTP5 / CS-A18CTP CU-A18CTP5 / CS-A24CTP CU-A24CTP5
To Next Page
