Panasonic CS-Z25TKEA Service Manual

11
Indoor
Model CS-Z25TKEA CS-Z35TKEA
POS (EAN) 5025232873319 5025232873333
Outdoor
Model CU-Z25TKEA CU-Z35TKEA
POS (EAN) 5025232873326 5025232873340
Compressor
Type Hermetic Motor / Rotary Hermetic Motor / Rotary
Motor Type Brushless (4-poles) Brushless (4-poles)
Output Power W 900 900
Indoor Fan
Type Cross-flow Fan Cross-flow Fan
Material ASG20K1 ASG20K1
Motor Type DC (8-poles) DC (8-poles)
Input Power W 47.3 47.3
Output Power W 40 40
Speed
QLo
Cool rpm 650 640
Heat rpm 670 680
Lo
Cool rpm 730 800
Heat rpm 810 880
Me
Cool rpm 910 1010
Heat rpm 1010 1140
Hi
Cool rpm 1100 1220
Heat rpm 1220 1400
SHi
Cool rpm 1200 1270
Heat rpm 1320 1450
Outdoor Fan
Type Propeller Fan Propeller Fan
Material PP PP
Motor Type DC (8-poles) DC (8-poles)
Input Power W – –
Output Power W 40 40
Speed Hi
Cool rpm 800 860
Heat rpm 800 890
Moisture Removal L/h (Pt/h) 1.5 (3.2) 2.0 (4.2)
Indoor
Airflow
QLo
Cool m
3
/min (ft
3
/min) 5.49 (194) 5.22 (184)
Heat m
3
/min (ft
3
/min) 5.71 (202) 5.60 (198)
Lo
Cool m
3
/min (ft
3
/min) 6.36 (225) 6.74 (238)
Heat m
3
/min (ft
3
/min) 7.22 (255) 7.50 (265)
Me
Cool m
3
/min (ft
3
/min) 8.35 (295) 8.73 (308)
Heat m
3
/min (ft
3
/min) 9.43 (333) 9.97 (352)
Hi
Cool m
3
/min (ft
3
/min) 10.40 (365) 10.70 (380)
Heat m
3
/min (ft
3
/min) 11.70 (415) 12.40 (440)
SHi
Cool m
3
/min (ft
3
/min) 11.43 (404) 11.20 (395)
Heat m
3
/min (ft
3
/min) 12.73 (450) 12.91 (456)
Outdoor
Airflow
Hi
Cool m
3
/min (ft
3
/min) 32.20 (1135) 34.40 (1215)
Heat m
3
/min (ft
3
/min) 32.20 (1135) 35.60 (1255)
Refrigerant
Cycle
Control Device Expansion Valve Expansion Valve
Refrigerant Oil cm
3
FW50S (450) FW50S (450)
Refrigerant Type g (oz) R32, 960 (33.9) R32, 1000 (35.3)
F-Gas
GWP 675 675
CO2eq (ton)
(Precharged Amount /
Maximum Amount)
0.648 / 0.732 0.675 / 0.759
