10
3. Specifications
Indoor
Model CS-Z25TKEA CS-Z35TKEA
POS (EAN) 5025232873319 5025232873333
Outdoor
Model CU-Z25TKEA CU-Z35TKEA
POS (EAN) 5025232873326 5025232873340
Performance Test Condition EUROVENT EUROVENT
Power Supply
Phase, Hz Single, 50 Single, 50
V 230 230
Min. Mid. Max. Min. Mid. Max.
Cooling
Capacity
kW 0.85 2.50 3.00 0.85 3.50 4.00
BTU/h 2900 8530 10200 2900 11900 13600
kcal/h 730 2150 2580 730 3010 3440
Running Current A – 2.45 – – 4.00 –
Input Power W 170 510 700 170 860 1.10k
Annual Consumption – 258 – – 435 –
EER CLASS – A – – A –
EER
W/W 5.00 4.90 4.29 5.00 4.07 3.64
BTU/hW 17.06 16.73 14.57 17.06 13.84 12.36
kcal/hW 4.29 4.22 3.69 4.29 3.50 3.13
ErP
Pdesign kW 2.5 3.5
SEER (W/W) 8.5 8.5
Annual
Consumption
kWh 103 144
Class A+++ A+++
Power Factor % – 91 – – 93 –
Indoor Noise (H / L / QLo)
dB-A 39 / 25 / 21 42 / 28 / 21
Power Level dB 55 / – / – 58 / – / –
Outdoor Noise (H / L / QLo)
dB-A 46 / – / – 48 / – / –
Power Level dB 61 / – / – 63 / – / –
Heating
Capacity
kW 0.85 3.40 5.40 0.85 4.00 6.60
BTU/h 2900 11600 18400 2900 13600 22500
kcal/h 730 2920 4640 730 3440 5680
Running Current A – 3.40 – – 4.20 –
Input Power W 165 700 1.31k 165 920 1.82k
COP CLASS – A – – A –
COP
W/W 5.15 4.86 4.12 5.15 4.35 3.63
BTU/hW 17.58 16.57 14.05 17.58 14.78 12.36
kcal/hW 4.42 4.17 3.54 4.42 3.74 3.12
ErP
Pdesign kW 2.8 3.6
Tbivalent °C -10 -10
SCOP (W/W) 4.5 4.4
Annual
Consumption
kWh 871 1145
Class A+ A+
Power Factor % – 90 – – 95 –
Indoor Noise (H / L / QLo)
dB-A 41 / 27 / 22 43 / 30 / 22
Power Level dB 58 / – / – 60 / – / –
Outdoor Noise (H / L / QLo)
dB-A 48 / – / – 50 / – / –
Power Level dB 63 / – / – 65 / – / –
Low Temp. : Capacity (kW) / I.Power (W) / COP 3.91 / 1.16k / 3.37 4.78 / 1.61k / 2.97
Extr Low Temp. : Capacity (kW) / I.Power (W) / COP 3.33 / 1.29k / 2.58 4.07 / 1.70k / 2.39
Max Current (A) / Max Input Power (W) 7.7 / 1.74k 8.3 / 1.82k
Starting Current (A) 3.40 4.20
