Panasonic CS-Z25TKEA Service Manual

23
6.2 Outdoor Unit
6.2.1 CU-Z25TKEA CU-Z35TKEA CU-Z42TKEA
<Top View>
<Front View><Side View>
<Side View>
Anchor Bolt Pitch
330 × 540
Space necessary for
installation
100 mm
100 mm
1000 mm
Unit : mm
3-way valve at Gas side
(Low Pressure)
2-way valve at Liquid side
(High Pressure)
22 (124) (62.6)
330
619
167
97
69
(20)
62
32
540 160
824 68.7
37 299
6.2.2 CU-Z50TKEA CU-Z71TKEA
(25)
7570.5
695
320
386
45
7.7
61334.7
(131)
72
875
3582
360.5
131
<Side View>
<Side View>
<Front View>
<Top View>
Unit: mm
2-way valve at Liquid side
(High Pressure)
3-way valve at Gas side
(Low Pressure)
Anchor Bolt Pitch
360.5 × 613
Space necessary for
installation
100 mm
100 mm
1000 mm
