Panasonic CS-Z25TKEA Service Manual

151
SAFETY
REF.
NO.
PART NAME & DESCRIPTION QTY. CS-Z42TKEA CS-Z50TKEA CS-Z71TKEA REMARK
1 CHASSIS COMPLETE 1 ACXD50C01590 ← ←
2 FAN MOTOR 1 ARW7676ACCB ← L6CBYYYL0194 O
3 CROSS-FLOW FAN COMPLETE 1 CWH02C1136 ← ←
4 BEARING ASSY 1 CWH64K1010 ← ←
5 SCREW - CROSS-FLOW FAN 1 CWH551146 ← ←
6 PARTICULAR PIECE 1 CWD933067B ← ←
7 EVAPORATOR 1 ACXB30C02270 ← ACXB30C02870
8 FLARE NUT (LIQUID) 1 CWT251048 ← ←
9 FLARE NUT (GAS) 1 CWT251032 ← CWT251033
10 CONTROL BOARD CASING 1 ACXH10-00720 ← ←
11 PARTICULAR PIECE 1 CWD933138 ← ←
12 TERMINAL BOARD COMPLETE 1 CWA28C2382 ← ← O
13 ELECTRONIC CONTROLLER - MAIN 1 ACXA73C40890 ACXA73C40900 ACXA73C40910 O
14 ELECTRONIC CONTROLLER - SUB 1 ACXA73-22640 ← ← O
15
ELECTRONIC CONTROLLER -
INDICATOR
1 ACXA73-22630 ← ← O
18 INDICATOR HOLDER 1 ACXD93-01960 ← ←
19 SENSOR COMPLETE 1 CWA50C3226 ← CWA50C2664 O
24 DISCHARGE GRILLE COMPLETE 1 ACXE20C00990 ← ←
25 BACK COVER CHASSIS 1 ACXD93-10180 ← ←
26 FULCRUM 2 ACXH62-00080 ← ←
27 VERTICAL VANE 8 ACXE24-00400 ← ←
28 VERTICAL VANE 3 ACXE24-00630 ← ←
29 CONNECTING BAR - LEFT 1 ACXE26-00190 ← ←
30 CONNECTING BAR - RIGHT 1 ACXE26-00200 ← ←
32 AIR SWING MOTOR - OUTER VANE 1 CWA981304 ← ← O
33 AIR SWING MOTOR - INNER VANE 1 CWA981299 ← ← O
34 CAP - DRAIN TRAY 1 CWH521259 ← ←
35
HORIZONTAL VANE COMPLETE -
OUTER
1 ACXE24C01030 ← ←
36
HORIZONTAL VANE COMPLETE -
INNER
1 ACXE24C00540 ← ←
38
CONTROL BOARD COVER -
COMPLETE
1 ACXH13C00150 ← ←
39 REMOTE CONTROL COMPLETE 1 CWA75C4264 ← ←
40 FRONT GRILLE COMPLETE 1 ACXE10C06780 ← ACXE10C06790
41 INTAKE GRILLE COMPLETE 1 ACXE22K00960 ← ←
42 GRILLE DOOR COMPLETE 1 ACXE14C00050 ← ←
43 AIR FILTER 2 ACXD00-00250 ← ←
44 CAP - FRONT GRILLE 3 ACXH52-00100 ← ←
45 SCREW - FRONT GRILLE 4 XTT4+16CFJ ← ←
46 DRAIN HOSE 1 ACXH85-00210 ← ←
47 INSTALLATION PLATE 1 CWH361098 ← ←
48
BAG COMPLETE - INSTALLATION
SCREW
1 CWH82C1942 ← ←
49 REMOTE CONTROL - CABEL 1 CWA221113 ← ←
50 BAG 1 ACXG86-00130 ← ←
51 SHOCK ABSORBER 1 ACXG70-00840 ← ←
52 SHOCK ABSORBER 1 ACXG70-00850 ← ←
53 C. C. CASE 1 ACXG50-39100 ACXG50-39110 ACXG50-39120
(NOTE)
 All parts are supplied from PAPAMY, Malaysia (Vendor Code: 00029488).
 “O” marked parts are recommended to be kept in stock.
