Panasonic CS-Z25UFRAW Service Manual

11
Indoor
Model CS-Z25UFRAW
POS (EAN) 5025232885435
Outdoor
Model CU-Z25UBRA
POS (EAN) 5025232885466
Indoor Fan
Type Cross Flow Fan
Material ASG33
Motor Type DC / Transistor (8-poles)
Input Power W 44
Output Power W 30
Speed
QLo
Cool rpm 520
Heat rpm 520
Lo
Cool rpm 610
Heat rpm 620
Me
Cool rpm 830
Heat rpm 880
Hi
Cool rpm 1040
Heat rpm 1140
SHi
Cool rpm 1090
Heat rpm 1190
Outdoor Fan
Type Propeller Fan
Material PP
Motor Type DC (8-poles)
Input Power W –
Output Power W 40
Speed Hi
Cool rpm 820
Heat rpm 780
Moisture Removal L/h (Pt/h) 1.5 (3.2)
Indoor
Airflow
QLo
Cool m
3
/min (ft
3
/min.) 5.0 (177)
Heat m
3
/min (ft
3
/min.) 5.0 (177)
Lo
Cool m
3
/min (ft
3
/min.) 5.8 (205)
Heat m
3
/min (ft
3
/min.) 5.9 (208)
Me
Cool m
3
/min (ft
3
/min.) 7.9 (280)
Heat m
3
/min (ft
3
/min.) 8.3 (290)
Hi
Cool m
3
/min (ft
3
/min.) (L/S) 9.8 (345) (163)
Heat m
3
/min (ft
3
/min.) (L/S) 10.4 (365) (173)
SHi
Cool m
3
/min (ft
3
/min.) 10.3 (360)
Heat m
3
/min (ft
3
/min.) 11.2 (395)
Outdoor
Airflow
Hi
Cool m
3
/min (ft
3
/min.) 28.7 (1015)
Heat m
3
/min (ft
3
/min.) 27.2 (960)
Refrigeration
Cycle
Control Device Expansion Valve
Refrigerant Oil cm
3
FW50S (320)
Refrigerant Type g (oz) R32, 920 (32.5)
Dimension
Unit
Height (I/D / O/D) mm (inch) 600 (23-5/8) / 542 (21-11/32)
Width (I/D / O/D) mm (inch) 750 (29-17/32) / 780 (30-23/32)
Depth (I/D / O/D) mm (inch) 207 (8-5/32) / 289 (11-13/32)
Pckg.
(Stacking
Condition)
Height (I/D / O/D) mm (inch) 281 (11-3/32) / 603 (23-3/4)
Width (I/D / O/D) mm (inch) 830 (32-11/16) / 891 (35-3/32)
Depth (I/D / O/D) mm (inch) 676 (26-5/8) / 396 (15-19/32)
Weight
Net (I/D / O/D) kg (lb) 13 (29) / 33 (73)
Gross (I/D / O/D) kg (lb) 15 (33) / 35 (77)

Panasonic CS-Z25UFRAW Specifications

General

Brand	Panasonic
Model	CS-Z25UFRAW
Category	Air Conditioner
Language	English
