Panasonic CS-Z25UFRAW Service Manual

141
21.2 Heat Mode Outdoor Air Temperature Characteristic
Condition
- Indoor room temperature: 20°C Dry Bulb/ -°C Wet Bulb
- Unit setting: Standard piping length, forced heating at 30°C, Hi fan
- Compressor frequency: Rated for Heating operation
- Piping length: 5m
- Voltage: 230V/240V
21.2.1 CS-Z25UFRAW CU-Z25UBRA
Outdoor Air Temperature (°C)
Outdoor Air Temperature (°C)
Outdoor Air Temperature (°C)
High Pressure (PSI)
-15 -13 -11 -9 -7 -5 -3 -1 1 3 5 7 9 11 13 15 17 19 21 23 25
-15 -13 -11 -9 -7 -5 -3 -1 1 3 5 7 9 11 13 15 17 19 21 23 25
-15 -13 -11 -9 -7 -5 -3 -1 1 3 5 7 9 11 13 15 17 19 21 23 25
-15 -13 -11 -9 -7 -5 -3 -1 1 3 5 7 9 11 13 15 17 19 21 23 25
Outdoor Air Temperature (°C)
5.00
2.50
3.00
3.50
4.00
4.50
3.000
2.500
2.000
1.500
1.000
0.500
0.000
4.00
4.50
3.00
3.50
2.00
2.50
1.00
1.50
0.00
0.50
435.113
507.632
362.594
290.075
217.557
145.038
72.519
0.000
2.00
1.50
1.00
0.50
0.00
35.0
40.0
45.0
30.0
25.0
20.0
15.0
10.0
5.0
0.0
Indoor Discharge
Air Temperature (°C)High Pressure (MPa) Current (A)Capacity (kW)
Outdoor Air
Temperature (°C)
-15
-7
2
7
30.95
33.13
36.09
36.81
24 40.92
Indoor Discharge
Air Temperature (°C)
Outdoor Air
Temperature (°C)
-15
-7
2
7
1.613 / 233.946
1.810 / 262.518
2.073 / 300.663
2.279 / 330.541
24 3.209 / 465.426
High Pressure
(MPa) / (PSI)
Outdoor Air
Temperature (°C)
-15
-7
2
7
2.260
2.880
3.620
3.400
24 4.052
Capacity
(kW)
Outdoor Air
Temperature (°C)
-15
-7
2
7
1.72 1.57
2.34
3.03
3.40
24 4.58
2.19
2.88
3.25
4.43
Current (A)
230V
240V
