Panasonic CS-Z25UFRAW Service Manual

140
21.1.3 CS-Z50UFRAW CU-Z50UBRA
Outdoor Air Temperature (°C)
Outdoor Air Temperature (°C)
Outdoor Air Temperature (°C)
Low Pressure (PSI)
0 2 4 6 8 10121416182022242628303234363840424446
0 2 4 6 8 10121416182022242628303234363840424446
0 2 4 6 8 10121416182022242628303234363840424446
Outdoor Air Temperature (°C)
0 2 4 6 8 10121416182022242628303234363840424446
8.00
5.00
6.00
7.00
1.200
1.000
0.800
0.600
0.400
0.200
0.000
4.00
5.00
6.00
7.00
3.00
2.00
1.00
0.00
174.045
145.038
116.030
87.023
58.015
29.008
0.000
4.00
3.00
2.00
1.00
0.00
14.0
12.0
10.0
8.0
6.0
4.0
2.0
0.0
Indoor Discharge
Air Temperature (°C)Low Pressure (MPa) Current (A)Capacity (kW)
Outdoor Air
Temperature (°C)
5
16
25
35
8.80
9.88
11.24
11.75
46 12.83
Indoor Discharge
Air Temperature (°C)
Outdoor Air
Temperature (°C)
5
16
25
35
0.776 / 112.549
0.770 / 111.679
0.869 / 126.038
0.916 / 132.855
46 0.967 / 140.251
Low Pressure
(MPa) / (PSI)
Outdoor Air
Temperature (°C)
5
16
25
35
5.962
6.162
5.586
5.000
46 4.103
Capacity
(kW)
Outdoor Air
Temperature (°C)
5
16
25
35
4.37 4.17
5.04
5.59
6.20
46 6.87
4.84
5.39
6.00
6.67
Current (A)
230V
240V
