Panasonic CS-Z25UFRAW Service Manual

17
Indoor
Model CS-Z50UFRAW
POS (EAN) 5025232885459
Outdoor
Model CU-Z50UBRA
POS (EAN) 5025232885480
Indoor Fan
Type Cross Flow Fan
Material ASG33
Motor Type DC / Transistor (8-poles)
Input Power W 44
Output Power W 30
Speed
QLo
Cool rpm 670
Heat rpm 740
Lo
Cool rpm 750
Heat rpm 830
Me
Cool rpm 1010
Heat rpm 1130
Hi
Cool rpm 1260
Heat rpm 1440
SHi
Cool rpm 1310
Heat rpm 1490
Outdoor Fan
Type Propeller Fan
Material PP
Motor Type DC (8-poles)
Input Power W –
Output Power W 40
Speed Hi
Cool rpm 720
Heat rpm 660
Moisture Removal L/h (Pt/h) 2.8 (5.9)
Indoor
Airflow
QLo
Cool m
3
/min (ft
3
/min.) 6.4 (226)
Heat m
3
/min (ft
3
/min.) 7.0 (247)
Lo
Cool m
3
/min (ft
3
/min.) 7.1 (251)
Heat m
3
/min (ft
3
/min.) 7.9 (279)
Me
Cool m
3
/min (ft
3
/min.) 9.6 (340)
Heat m
3
/min (ft
3
/min.) 10.7 (380)
Hi
Cool m
3
/min (ft
3
/min.) (L/S) 11.9 (420) (198)
Heat m
3
/min (ft
3
/min.) (L/S) 13.6 (480) (227)
SHi
Cool m
3
/min (ft
3
/min.) 12.4 (440)
Heat m
3
/min (ft
3
/min.) 14.0 (490)
Outdoor
Airflow
Hi
Cool m
3
/min (ft
3
/min.) 39.7 (1400)
Heat m
3
/min (ft
3
/min.) 36.4 (1285)
Refrigeration
Cycle
Control Device Expansion Valve
Refrigerant Oil cm
3
FW50S (450)
Refrigerant Type g (oz) R32, 1.10k (38.8)
Dimension
Unit
Height (I/D / O/D) mm (inch) 600 (23-5/8) / 695 (27-3/8)
Width (I/D / O/D) mm (inch) 750 (29-17/32) / 875 (34-15/32)
Depth (I/D / O/D) mm (inch) 207 (8-5/32) / 320 (12-5/8)
Pckg.
(Stacking
Condition)
Height (I/D / O/D) mm (inch) 281 (11-3/32) / 796 (31-11/32)
Width (I/D / O/D) mm (inch) 830 (32-11/16) / 1049 (41-5/16)
Depth (I/D / O/D) mm (inch) 676 (26-5/8) / 460 (18-1/8)
Weight
Net (I/D / O/D) kg (lb) 13 (29) / 42 (93)
Gross (I/D / O/D) kg (lb) 15 (33) / 47 (104)
