Parts List
REPLACEMENT PARTS LIST
Model: CT-27DC50B
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important
for safety. When replacing any of these components use only manufacturer’s specified parts.
228-00
PARTS LIST
R6567 ERJ6GEYJ222 RES,M 2.2K-J-1/10
R6568 ERJ6GEYJ471 RES,M 470-J-1/10
R6570 ERJ6GEYJ103 RES,M 10K-J-1/10
SWITCHES
S010 EVQPBD05R SWITCH
S011 EVQPBD05R SWITCH
S012 EVQPBD05R SWITCH
S013 EVQPBD05R SWITCH
S014 EVQPBD05R SWITCH
S015 EVQPBD05R SWITCH
S016 EVQPBD05R SWITCH
S020 EVQPBD05R SWITCH
S021 EVQPBD05R SWITCH
S022 EVQPBD05R SWITCH
S023 EVQPBD05R SWITCH
S024 EVQPBD05R SWITCH
S025 EVQPBD05R SWITCH
TRANSFORMERS
T001 TLP16297 TRANSFORMER, POWER SUPPLY
T501 TLH15452
TRANSFORMER, HORIZONTAL
DRIVER
T502 ETE19Z30AY
TRANSFORMER, HORIZONTAL
COUPLING
T551 KFT4AB143F TRANSFORMER, FLYBACK
T801 ETS29AK3L5NC TRANSFORMER, SWITCHING
T861 ETS28AV115AC TRANSFORMER
CRYSTALS/FILTERS
X001 TSSA010 CRYSTAL
X101 M1969M SAW FILTER
X102 EFCS4R5MW5BA FILTER, BANDPASS
X201 SFSH4R5MDB CRYSTAL
X501 TAFCSB503F38 CRYSTAL, CLOCK
REF NO. PART NO. DESCRIPTION
X601 TSS2AA001 CRYSTAL, 3.58MHZ
OTHERS
M001 ETC33X82NA CY
TNR001 ENV56D37G3R TUNER
M002 EUR511503 TRANSMITTER, REMOTE CONTROL
M003 UR51EC975A BATTERY COVER, REMOTE CONTROL
M004 KRCBC160928B FERRITE
M005 M68LGL061X CRT
M006 TAS2AA0015 SPEAKER 8-OHM 5W
M007 TBM2A10143 BADGE, PANASONIC
M008 TXFBX15BSER ASSY, 13-KEY BUTTON
M009 TJS2AC00301 CRT SOCKET
M010 TKP2AA0292S PANEL TRAY
M011 TKU2AC1501S ASSY, CABINET BACK
M012 TKX2AA0071 IR GUIDE
M013 TKX2AA0081 IR HOLDER
M014 TKY2AA1702S ASSY, CABINET FRONT
DY TLY2AA006 DEFLECTION YOKE
M015 TMX2AE0051 CHASSIS RAIL (R)
M016 TMX2AE0052 CHASSIS RAIL (L)
M017 TMW2AX006 DVD BRACKET
M018 TNAX007S ASSY, DVD UNIT
M019 TQB2AA0339 MANUAL, OWNERS
M020 TSXL136 FLAT CABLE
M021 TSX2AA0251 LINE CORD
M022 TXF3A01ADR CRT GROUND LEAD WIRE ASSEMBLY
M023 0FMK014ZZ CONVERGENCE CORRECTOR STRIP
DEG 0LK19045A DEGAUSSING COIL
D3331 GP1F32T AUDIO OUTPUT
JK3001 TJB2AA0181 TERMINAL, A/V
JK3002 TJB2AA0046 TERMINAL, FRONT A/V
JK3003 TJB2AA0171 TERMINAL, S-VHS
REF NO. PART NO. DESCRIPTION
