- 6 -
Receiver Feature Table
FEATURE
Chassis NA6DVD
Tunning system 96K
# of channels 181
Menu language English
Closed Caption X
V-Chip X
75 Ω input X
Remote Model # EUR511503
Picture tube M68LGL061X
Black Face Regular Tube X
Comb Filter 3 Line Digital
H. Edge Correction X
V/A Norm - Both X
MTS/SAP/DBX X
AI Sound X
Bass/Bl/Tre Control X
Surround X
Built-in audio power 5Wx2 (10%)
# of speakers 2
A/V in (rear/front) 2(2/1)
S-VHS Input (rear/front) 1/0
Audio Out
(FAO & VAO)
X
Digital Optical Output X
Headphone Jack X
Dimensions mm
(WxDxH) in
665.2x536x599.7
262x211x236
Weight (kg/lbs) 35/77
Power source (V/Hz) 120/60
Anode voltage 29.25kV ± 1.25kV
Video input jack
1V
p-p
75Ω, phono jack
Audio input jack 500mV RMS 47kΩ
FEATURE
BOARD PART NUMBER DESCRIPTION
A TNPH0353* Main Chassis
C TNP2AA047AB* CRT Output
G TNPA1736* Video Input (front)
JJ TNPA1804* A/V Switch and A/V Decoder
K TNPA1737* Customer Controls
M TNPA1734* DVD-TV CPU Interface
P TNPA1738* DVD Power Supply
W TNPA1735* Connector Interface Board
* When ordering, please add an “s” to the part
number, for example TNPH0353 should be
ordered as TNPH0353S.
Specifications are subject to change without notice or obligation.
Dimensions and weights are approximate.
