Panasonic CU-MC140KE - Dimensions; CS-MC90 KE Indoor Unit Dimensions

– 11 –
MAC9702008C2
CS-MC90KE
Dimensions
CS-MC90KE
Relative position between the indoor unit and the installation plate <Front View>
(45)(410)
<Back View>
Installation plate hooks
Drain ports
Gas
side
Liquid
side
Remote control transmitter
57
142
16
790
48.5
60
290
<Front View>
175
61
34.5
52
direction
Air intake
Air outlet
direction
Left piping hole
Right piping hole
290
115
55
60
2100
Below
(44)
710
(45)
276
7
(64)
(115)
100 100
Slot (2 places)
Slot (2 places)
Centre notch
Indoor unit external
dimensions line
Installation plate
Left piping hole
Arrow
Arrow
Centre
Right piping hole
Installation plate positioning gauge
350
7
457
13.5
